Fully Automatic Single Die Dron Making Machine
90000 INR/Piece
Product Details:
- Grade Semi-Heavy Duty Industrial Grade
- Type Fully Automatic Single Die Dron Making Machine
- Material Mild Steel (MS) Body with high-grade components
- Capacity 30,000-45,000 pieces per 8 hr shift
- Computerized No
- Control System Automatic Panel with Push Button Controls
- Cutting Speed 1500-2000 pieces/hr
- Click to View more
X
Fully Automatic Single Die Dron Making Machine Price And Quantity
- 01 Piece
- 90000 INR/Piece
Fully Automatic Single Die Dron Making Machine Product Specifications
- 1.5 kW
- 360 kg approx.
- 220V / 50Hz, Single Phase
- Semi-Heavy Duty Industrial Grade
- One year of Motor and Blower
- Mild Steel (MS) Body with high-grade components
- Automatic Panel with Push Button Controls
- 30,000-45,000 pieces per 8 hr shift
- Industrial Blue + Silver Finish
- No
- 1820 mm x 780 mm x 1650 mm
- 4-12 inch adjustable
- 1500-2000 pieces/hr
- 80-350 GSM
- Fully Automatic Single Die Dron Making Machine
Fully Automatic Single Die Dron Making Machine Trade Information
- 5-7 Days
- Yes
- All India
Product Description
Technical Specifications
| Model No. | GT-D01 |
| Die Size | 4"-14" |
| Production | 900-1400 Pcs/Hr |
| Raw Material | 80 GSM to 180 GSM |
| Power Source | 220V, 50Hz |
| Electric Motor | 1HP |
| Power Consumption | 1-1.5 Unit/Hr |
| Dimension | 32"(L)x26"(W)x68"(H) |
| Weight | 250kg |
Free Accessories
| Heater Set of Free Dies |
| Pressure Spring = 2 |
| Long Spring = 1 |
| Die Connector = 4 |
| Spanner Set |
| Rubber Pad |
Efficient Production with Automation
This single die dron making machine optimizes productivity, achieving up to 45,000 drons in an 8-hour shift. Its integrated automatic and manual feed capability streamlines operations for a single operator, reducing manual workload. Automated controls and push-button operations minimize human error while increasing consistency in output. The machines industrial-grade build ensures durability and reliability, making it a strong asset for daily commercial use.
Versatile Material Handling and Customizable Output
Capable of processing paper, lamination sheets, and board paper (80350 GSM), the machine adapts to various production requirements. The cutting size is fully adjustable between 4 to 12 inches, allowing for flexible product design. An integrated hot air blower supports lamination applications, broadening the range of finished products. This versatility makes the machine suitable for factories, wholesalers, and retailers seeking customizable solutions.
FAQs of Fully Automatic Single Die Dron Making Machine:
Q: How does the automatic feeding system work on this dron making machine?
A: The machine supports both automatic roll feeding and manual sheet feeding. For bulk production, the automatic roll feed efficiently processes long rolls of raw material, while the manual sheet feed option is available for smaller runs or specialized material requirements.Q: What raw materials can be used with this machine, and what are the size and thickness options?
A: This machine is compatible with paper, lamination sheets, and board paper from 80 to 350 GSM. The cutting size is adjustable, allowing for production of drons between 4 to 12 inches, accommodating various packaging and serving needs.Q: What safety features are integrated into the machine for operator protection?
A: The machine is equipped with safety features such as an emergency stop button and overload protection. These safeguards help ensure the safety of the single operator required to manage the machines operations.Q: Where can the Fully Automatic Single Die Dron Making Machine be installed?
A: This machine is suitable for installation in industrial settings, manufacturing units, and high-volume retail locations. Installation support and training are provided by the manufacturer upon request to ensure proper setup and optimized use.Q: What is the production capacity and speed of this machine?
A: The machine can produce 1,500 to 2,000 drons per hour, reaching a total of 30,00045,000 drons in a standard 8-hour shift. This high throughput is ideal for businesses requiring large-scale output with minimal labor.Q: How is the machine controlled and what are its power requirements?
A: Operation is managed via an automatic panel with push button controls, ensuring straightforward and reliable management. It requires a 220V / 50Hz single-phase power supply with a recommended stabilizer, and consumes only 1.5 kW of power.Q: What benefits does the integrated hot air blower provide for lamination?
A: The integrated hot air blower enables seamless lamination of paper drons on the machine, improving product durability and presentation. This feature delivers consistent lamination quality and reduces manual intervention, enhancing overall productivity.Tell us about your requirement
