Automatic Zigzag Paper Plate Making Machine

Automatic Zigzag Paper Plate Making Machine

Name: Automatic Zigzag Paper Plate Making Machine
Brand: GREENTECH ENGINEERING
Price: 160000 INR
Availability: InStock

180000.0 INR/Piece

Get a Price/Quote

Product Details:

Warranty One year of Motor and Programmable Timer
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Automatic Zigzag Paper Plate Making Machine Price And Quantity

Price 180000.0 INR/Piece
Minimum Order Quantity 1 Piece

Automatic Zigzag Paper Plate Making Machine Product Specifications

Warranty One year of Motor and Programmable Timer

Automatic Zigzag Paper Plate Making Machine Trade Information

Delivery Time 5-7 Days
Sample Available Yes
Main Domestic Market All India

Product Description

Technical Specifications

Model No.	GT-P09
Die Size	4"-18"
Production	2700-3000 Pcs/Hr
Raw Material	80 GSM to 450 GSM
Power Source	220V, 50Hz
Electric Motor	2HP
Power Consumption	2.5-3 Unit/Hr
Oil Tank Capacity	45 Ltrs
Weight	350kg

Free Accessories

Heater Set of Free Dies

Teflon Sheet = 1

Die Connector = 8

Spanner Set

Rubber Pad

Robust and Versatile Construction

Built with an MS heavy-duty frame, this machine ensures durability even during continuous operation. Its compatibility with plate sizes from 4 to 14 inches, along with support for different paper types such as silver and white, makes it a versatile choice for large-scale plate manufacturing needs.

High Production and Automation Efficiency

Thanks to its advanced automated feeding and auto ejection systems, the machine achieves approximately 2000 plates per hour, minimizing manual intervention and increasing overall productivity. The zigzag die type enhances the aesthetic appeal and structural strength of the plates.

User-Friendly Operation and Maintenance

Designed for easy day-to-day use, this machine operates on a single-phase power supply and features straightforward manual die height adjustment. Maintenance remains simple, and quick troubleshooting is possible, reducing downtime for operators.

FAQ's of Automatic Zigzag Paper Plate Making Machine:

Q: How does the automated feeding system benefit production efficiency?

A: The automated feeding system streamlines the plate-forming process by continuously supplying the material, reducing manual effort and enabling the machine to produce up to 2000 plates per hour. This leads to consistent throughput and higher productivity.

Q: What types and sizes of paper plates can the machine manufacture?

A: This machine accommodates a wide plate size range from 4 to 14 inches and supports both silver and white paper types, making it suitable for varied customer requirements across catering and packaging sectors.

Q: Where can this machine be installed, and is any special power supply required?

A: The machine is suitable for installation in factories, workshops, or small-scale production units. It operates efficiently on a standard single-phase electrical supply, eliminating the need for complex wiring or heavy store infrastructure.

Q: When should the die height be adjusted, and how is it done?

A: Die height adjustment is necessary when changing plate sizes or paper thickness types. The machine features a manual adjustment mechanism, allowing operators to easily fine-tune the die for optimal results.

Q: What is the process for addressing maintenance needs?

A: Maintenance is straightforward due to the machine's design. Regular cleaning and inspection of key components-such as the feeding line, die, and ejection system-are recommended. The machine offers easy access for servicing to minimize downtime.

Q: What warranty coverage is provided with this machine?

A: A one-year warranty is included, which covers the motor and programmable timer. This ensures reliable performance and timely support in case of any operational issues within the warranty period.
